1 review(s) | Add review

· Availability: In Stock
· Estimated delivery time: 4/5 days

Prices 21 % less for customers outside of EU (World Wide Shipping)

107,44 € (130,00 € TAX Inc.)
  • Description
  • Specifications
  • Reviews (1)
  • Customers
  • How to buy?

The BIG SIGNAL CQ-11 antenna is a single element Full-Wave Quad design for 27 MHz. Ideal for use in local QSOs with vertical polarization and to work DX with his low radiation angle and low noise.

Why choose the CQ-11 antenna versus a traditional vertical?

· Full wavelength, reaching maximum efficiency in TX / RX because oit has no coils or adaptation elements.
· Very low noise because it is closed antenna, which will attenuate the QRM and improve the reception of weak signals in DX.
· Performance superior to the prestigious verticals.
· Very low radiation angle even installed at low height, essential for the DX.
· 3,90 meters of total length, forgetting the problems with the wind.
· Super robust construction of high quality, without maintenance of life.
· Easy installation because the weight is super light.

BIG SIGNAL - Make the difference



Specifications:

· Band: 27 MHz.
· Gain: 6,55 dBi. @1
 λ
· Polarization: Vertical.
· Radiation diagram: Near omnidirectional.
· SWR: 1,1:1 ~ 1,5:1.
· Impedance: 50 Ohm.
· Power rating: 2.000 W.
· Total wide: 3,90 m / 12,79 ft
· Total height: 3,90 m / 12,79 ft
· Weight: 3 Kg / 6,61 lb
· Wind survival: > 160 Km/h. / 100 mph


Construction details:

· Plate to Mast: 200 x 150 x 6 mm
· Spiders: Angled design of 20 x 3 mm.
· Hardware: Stainless Steel, W4 grade.
· Spreaders Arms: 14 x 7 mm reinforced fiber cloth and protective layer for the sun.
· Cable: BIG SIGNAL - Wire. Special copper cable with polyethylene (PE) sheath for excellent weather protection and mechanical resistance.
· Feeding: PL-UHF connector.



Reviews

  1. JOSE ANTONIO (30VDX01)02 Jul, 2018 - 14:38

    El que me conoce bien sabe que no he parado de probar antenas verticales para 11 metros . Hoy trabajo con la que para mi es la mejor vertical para 11 metros,por que ( aunque no lo sea del todo) , su rendimiento supera con creces a las 5/8 , con el añadido de recibir de igual manera a las verticales que las direccionales.
    lo mejor de todo, la ausencia de QRM.
    buen tabajo
    30VDX01 Jose Antonio (Valencia)
